StellaHome Repeater Family

Boosts mobile signal in 2-5 rooms

StellaHome Repeater Family

SKUBandFrequency MHzRegionPrice ex VAT
SD-RP1002-LGDWHB20/ B8/ B3/ B1/ B7800/ 900/ 1800/ 2100/ 2600 EU€1432
SD-RP1002-VLGDWB28/ B20/ B8/ B3/ B1700/ 800/ 900/ 1800/ 2100EU€1432
SD-RP1002-LGWB20/ B8/ B1800/900/2100 EU€856
SD-RP1002-GDWB8/ B3/ B1900/1800/2100EU€856
SD-RP1002-LGB20/B8800/ 900 EU€629
SD-RP1002-GWB8/ B1900/ 2100 EU€629
SD-RP1002-GDB8/ B3900/ 1800EU€629
SD-RP1002-LB20 800 EU€408
SD-RP1002-GB8900EU€408
SD-RP1002-DB31800EU€408
SD-RP1002-WB12100EU€408
  • Included in the price- 1 outdoor antenna/1 indoor antenna/ 12m outdoor cable/ repeater + power supply.
  • More bands deliver increased bandwidth- faster data speed.
  • Coverage: 2-5 rooms
  • Designed, manufactured and tested in Ireland, EU.
  • Supports all operators.
  • Supports unlimited numbers of users.
  • CE approved. Meets ComReg specifications.

How It Works

Stella Doradus repeater system diagram



Professional grade repeaters

  1. The antenna on the roof receives the mobile signal from all operators, and sends it down the cable to the StellaHome repeater.
  2. The StellaHome repeater amplifies the signal and sends it around the house.
  3. All mobile devices can now communicate with this enhanced signal.



Frequencies

There are several frequency options for the StellaHome repeater. Choose to boost just one frequency like 900MHz for voice calls,  or all 5 mobile frequencies, enabling 2G, 3G ,4G and 5G. The more frequencies added, the better the coverage and the higher the data speeds.



Coverage

The StellaHome repeater kit contains 1 internal antenna. This antenna provides 30M2 X 30M2 of coverage in open space.

However, this is only in open space. In practice, it equates to about 2-5 sized rooms in a typical building layout. The coverage depends on the type of walls inside the building.

Concrete or metal insulated walls reduce the coverage, whereas plaster board walls and  wide open internal spaces allow an increase in coverage.

Mobile signal strength diagram

See building A and building B above.

All the walls are concrete block and the doors are wooden.

Building A:  In this building, just one antenna is sufficient. The signal will pass through the  doors to the three smaller rooms.

Building B:  This building  has a corridor separating the rooms. To achieve maximum coverage with only one antenna, the antenna is placed in the corridor as shown. Notice the reduction of signal in all the rooms. Interior concrete block walls reduce coverage significantly. If more reliable coverage is required  in the rooms, more antennas will be necessary. We recommend an iRepeater in this case.



A Closer Look
Stella Doradus repeater





Installation



A  “loose” installation is recommended to begin with.

  1. Install the outdoor panel antenna in a location where there is good mobile signal (usually this is on the roof).
  2. Using the supplied 12m cable, connect it to the antenna and bring it inside the house to the StellaHome repeater.
  3. Attach this cable to the right hand side of the repeater. Then attach the indoor panel antenna to the repeater.
  4. Plug in the power supply.

*All kits in the StellaHome family are supplied with an exterior panel antenna, except the Stellahome 5 band, which uses an exterior Yagi antenna.
